Kemppi P0680 - Minarc Evo 140 VRD 1~ Phase Portable MMA/TIG Welder 61002140AU
Outstanding welding performance is no overstatement. Every element of Minarc Evo 180 is designed to meet the needs of professional welders on the move. Where size, weight and welding quality are concerned, there is no equal.
Ideal for site use, you can use Minarc Evo 180 from mains or generator power supplies, even with extra-long supply cables. Minarc Evo is easy to carry, so you can normally take everything you need in one journey.
Features:
- Premium welding performance
- Use with all electrode types
- Use with long supply cables
- PFC technology for ultimate energy efficiency
- High current output and duty cycle
- Lightweight and portable
- Robust and durable
- Precise lift TIG technology
- Mains network or generator use
- Optional remote control
Specifications:
- Connection voltage 1~ 50/60 Hz: 230 V ±15 %
- Fuse (delayed): 10 A
- Minimum generator power: 5.5 kVA
- Output (MMA) 28% ED: 140 A/25.6 V (28 %)
- Output (MMA) 100% ED: 80 A/23.2 V
- Open circuit voltage: 12 V
- Stick electrode sizes: 1.5…3.25 mm
- Welding range (MMA): 10A/15V - 140A/38V
- Welding range (TIG): 10A/1V - 150A/37V
- Operating temperature range: –20…+40 °C
- External dimensions LxWxH: 361 × 139 × 267 mm
- Weight (no accessories): 5.4 kg
- Degree of protection: IP23S
- Standards: IEC 60974-1 IEC 60974-10 IEC 61000-3-12
Warranty:
- Kemppi 3 year warranty for parts and labor
